| Technical data | |
| Overall length | 12865 mm |
| Overall width | 4320 mm |
| Overall height | 4855 mm |
| Upper width | 3640 mm |
| Track length | 5865 mm |
| Track gauge | 2780 mm |
| Tail swing radius | 4220 mm |
| Min.Ground Clearance | 880 mm |
| Track shoe width | 650 mm |
| Boom length | 7000 mm |
| Bucket arm length | 3000 mm |
| Bucket capacity | 4.6 m³ |
| WEIGHT | |
| Total weight | 76200 kg |
| WORKING RANGE | |
| Max. digging height | 10120 mm |
| Max. digging depth | 6600 mm |
| Max. digging distance | 10850 mm |
| Min. slewing radius | 5130 mm |
| Max. height at min. slewing radius | 8800 mm |
| ENGINE | |
| Model | Isuzu 6WG1 |
| Rated power | 377 kW/1800 rpm |
| Travel speed | 2.9\4.5 km/h |
| OUTPUT | |
| Slewing speed | 8 rpm |
| Fuel tank | 940 L |
| Engine coolant | 70 L |
| Engine oil | 57 L |
Super adaptation
More than 20 kinds of optional working devices, good protection of the engine with multiple filtration system, independent oil radiator to keep proper working temperature.
Longer lifetime
By comprehensive testing system, the designed lifetime reaches 25000 hours, 15% less pressure of key components compared with 40 tonnage models, but 30% longer lifetime.
Low maintenance cost
Much more convenient maintenance operation, durable oil and filters to make longer maintenance period, 50% less expense.
