SY550HD
52 T
Specifications
| Overall length (in transportation state) | 12076 |
| Overall width | 3360 |
| Overall height (in transportation state) | 3700 |
| Upper width | 3290 |
| Overall height (cab top) | 3470 |
| Width of standard track plate | 600 |
| Track gauge | 2740 |
| Minimum ground clearance | 560 |
| Slewing radius of tail | 3765 |
| Grounding length of track | 4415 |
| Track length | 5440 |
| Track height | 1220 |
| Length of cab top | 1950 |
| Ground clearance of counter weight | 1355 |
| Overall length (excluding working device) | 6500 |
| Length on the ground (in transportation mode) |
6570 |
| Overall weight | 52000kg |
| Bucket capacity | 3.1~3.6m³ |
| Traveling speed (high/low) | 5.4/3.1(km/h) |
| Engine | |
| Model | 6WG1XKSC-01 |
Benefits & Features
Super adaptation
More than 20 kinds of optional working devices; good protection of the engine with multiple filtration systems.
Longer lifetime
By using a comprehensive testing system, the designed lifetime reaches 25000 hours, 15% less pressure on key components compared with 40-tonnage models, but 30% longer lifetime.
Low maintenance costs
Much more convenient maintenance operation, durable oil and filters to make a longer maintenance period, and 50% less expense.
