Specifications
Engine model | ISUZU GH-6HK1 |
Engine power | 212.0 kW /228.24 hp. |
Engine capacity | 7.79 l |
Fuel tank | 540 l |
Power digging bucket | 204.0 kN |
Arm Digging Force | 153.0 kN |
Track rollers on each side | 9 |
Standard boom | 6.15 m |
Standard handle | 3.3 m |
Bucket capacity | 1.65m³ |
Benefits & Features
HIGH EFFICIENCY AND LOW CONSUMPTION
The ISUZU GH-6HK1 Engine with Tier 3 emission standard adopts the brand new controller to realize real-time precise fuel injection, making the fuel burn more sufficiently. Under same working environment, the fuel consumption reduces by over 10 percent.
The self-developed DOMCS dynamic optimized intelligent control system realizes the perfect match of the engine and the main pump, making the movement more fast and also prolonging the service life.
HIGH RELIABILITY
The customized key components by global well-known brands, passing endurance test, adapt to various rough working environment.
USERS’ FRIENDLY DESIGN
The brand-new damping system, cab with extra-large view, strengthened noise reduction design, greatly improve the operation experience.
