| Overall length | 3,575 mm | |
| Overall width | 980/1,350 mm | |
| Overall superstructure width | 980 mm | |
| Overall height above cab | 2,420 mm | |
| Rear length | 920 mm | |
| Track width | 750/1,120 mm | |
| Undercarriage length | 1,585 mm | |
| Undercarriage width (dozer blade) | 980/1,350 mm | |
| Blade height | 270 mm | |
| Track link width | 230 mm | |
| Tail swing radius | 920 mm | |
| Distance (centre) between crawler wheel and guide wheel | 1,220 mm | |
| Boom length | 1,810 mm | |
| Bucket arm length | 1,130 mm | |
| Bucket capacity | 0.04 m³ | |
| Working range | ||
| Max. horizontal reach on the ground | 4,000 mm | |
| Max. excavation depth | 2,360 mm | |
| Max. vertical reach | 3,665 mm | |
| Max. dumping height | 2,635 mm | |
| Min. slewing radius | 1,705 mm | |
| Max. excavation depth, vertical wall | 2,215 mm | |
| Working machine height at min. slewing radius | 2,745 mm | |
| Weight | ||
| Total weight | 1,750 kg | |
| Engine | ||
| Model | YANMAR 3TNV80F | |
| Rated power | 14,6 kW | |
| Max. torque | 64,7 Nm/1,800 upm | |
| Displacement | 1267 ccm | |
| HYDRAULIC SYSTEM | ||
| Main pumps | 1 Adjustable axial piston pump | |
| Maximum oil flow | 1 x 55 l/min | |
| Travel drive | 2 Adjustable axial piston pumps | |
| Slewing gear | 1 Adjustable axial piston pump | |
| Pressure limiting valve settings | ||
| Boom circuit | 270 bar | |
| Slewing circuit | 162 bar | |
| Drive circuit | 270 bar | |
| Pilot control circuit | 35 bar | |
| Output | ||
| Slewing speed | 10 rpm | |
| Max. ground speeds | fast 3.7 km/h slow 2.1 km/h | |
| Max. traction force | 15.6 kN | |
| Climbing ability | 30° | |
| ISO bucket breakaway force | 15.2 kN | |
| ISO arm tear-out force | 9.2 kN | |
| Service refill capacities | ||
| Fuel tank | 23 l | |
| Engine coolant | 3,8 l | |
| Engine oil | 2 l | |
| Travel drive (per side) | 0,4 l | |
| Hydraulic oil tank | 21 l | |
Quiet and low-vibration engine
+ Efficient, powerful load-sensing hydraulic system
+ responsive, precise control
+ Ergonomic, comfortable seat
+ Clear instruments and a large, high-resolution color display
+ Optimum visibility
+ Powerful heating
Standard connections for commercially available accessories
+ Low weight and compact dimensions
+ All cladding elements are made of metal.
+ All important maintenance points are very easily accessible.
+ ROPS/FOPS-certified for safety in operation
