| Technical data | |
| Overall length | 7690mm |
| Overall width | 2490 mm |
| Overall height | 3200 mm |
| Min.Ground Clearance | 360 mm |
| Boom length | 4600 mm |
| Bucket arm length | 2100 mm |
| Bucket capacity | 0.58 m³ |
| WEIGHT | |
| Total weight | 13500 kg |
| WORKING RANGE | |
| Max. digging height | 8600 mm |
| Max. digging depth | 4800 mm |
| Min. slewing radius | 2400 mm |
| Max. height at min. slewing radius | 6800 mm |
| ENGINE | |
| Model | Isuzu 4HK1 |
| Rated power | 120 kW/2000rpm |
| Travel speed | 10\37 km/h |
High efficiency and low consumption
The Tier 3 Isuzu 4HK1 Engine can precisely controls the fuel jet according to the various working modes, to make the fuel burn more sufficiently.
Comfortable operation
The brand-new damping system, cab with extra-large view, strengthened noise reduction design, greatly improve the operation experience.
Strong cross-country traveling ability
The four-wheel driving brings about strong cross-country traveling ability, able to adapt tough working environment.
Flexible operation
High-speed traveling ability shortens the running time, making the space changes more conveniently.
